The Merida eOne-Sixty is built around compact Shimano Steps motors, the Shimano design ethos is around natural riding, and the physical design of the motor allows Merida designers to create very short chainstays which deliver agile and "regular bike" geometry.
To give the e-full suspension bikes precise steering, fantastic 'rolling over obstacles' behaviour yet maximum traction, we have combined a 29er front wheel with a 2.5" tyre and a 650B rear wheel, equipped with a slightly wider 2.6" tyre. The perfect combination of precision, playfulness and traction allowing you to feel planted when tackling the most demanding of trails.
| Part | Specs |
|---|---|
| Frame | Racelite 6061 double-butted heat-treated hydroformed aluminum, casted motor bracket, molded chainstay protection, Energy Guard battery cover |
| Fork | Marzocchi Z1 Ebike+ Air 160mm suspension travel Tapered 51mm fork offset |
| Shock | FOX FLOAT DPX2 Performance, trunnion mount |
| Wheel Front | Shimano SLX M7110 15x110 hub on 29in MERIDA EXPERT TR 29mm wide Alloy Rim |
| Wheel Rear | Shimano SLX M7110 12x148 MICRO SPLINE hub on 27.5in MERIDA EXPERT TR 29mm wide Alloy Rim |
| Tyre Front | Maxxis Assegai, 3C MaxxGrip, EXO+, TR, folding, 29" x 2.5" |
| Tyre Rear | Maxxis Minion DHR II, 3C, EXO+, TR, folding, 27.5" x 2.6 |
| Chainring | Shimano CRE80, 34 tooth |
| Cranks | Shimano FC-EM600 |
| Rear Mech | Shimano XT RD-M8100 Shadow+ |
| Shifter | Shimano XT SL-M8100 |
| Cassette | Shimano Deore M6100 (10-51T) |
| Chain | KMC e12T EPT |
| Pedals | Shimano M520 Trail SPD |
| Chain Guide | MRP upper slider |
| Brakes | Shimano SLX M7120 |
| Rotor Front | Shimano RT64 203mm |
| Rotor Rear | Shimano RT-EM600 203mm |
| Headset | Superstar Components Type 2 and Type H Cups With Sealed Bearings |
| Stem | MERIDA EXPERT eTRII - aluminium 35mm diameter 0° stem angle GoPro & Supernova mount 40 mm |
| Handlebars | MERIDA EXPERT eTR 780mm width 20mm rise |
| Grips | DMR Death Grips |
| Seat Collar | Merida Expert, single bolt |
| Seatpost | Merida Expert TR dropper, zero setback, Shimano MT500 remote lever, 170mm drop |
| Saddle | Merida Expert CC, V-mount |
| Motor | Shimano STEPS EP8, 85 Nm max torque |
| Battery | Shimano STEPS E8036, integrated 630wh |
| Display | Shimano STEPS E7000 |
